Smart Door Lock- Semi-automatic lock JSL1808-F
Smart Door Lock- Semi-automatic lock JSL1808-F
• Metal frame
• Class 5A drilled panels
• Patented clutch design
• Highly integrated internal structure design
• Customizable door magnets
• PC material one-time hot press molding: high temperature/low temperature resistance, resistance resistance
• Metal frame and handle painting process: primer + color paint + varnish glaze
• Door lock networking
• Semiconductor fingerprints
• Touchscreen input
• Door opening app for your phone
• Numeric code to open the door
• Can be redeveloped
• Suitable for hotels, apartments, rental houses
| Specification： | |
| Outer lock size | 308*71*25 |
| Panel material | High quality aluminum alloy |
| Surface technology | Fuel injection + electrophoresis |
| Fit the lock body | 6052、6068 |
| Door thickness requirements | 40-110mm |
| Lock head | Super Class B mechanical lock |
| Operating temperature | -20°C-+60°C |
| Networking mode | Bluetooth、Lora、Nb-iot（choose one from three） |
| Power supply mode | 4 alkaline batteries |
| Low voltage alarm | 4.8V |
| Standby current | 60μm |
| Operating current | ＜200mA |
| Unlock time | ≈1.5s |
| Key type | Capacitive touch key |
| Fingerprint head type | Semiconductor(ZFM-10)<0.001%<1.0% |
| FFR | <0.001% |
| FAR | <1.0% |
| Number of passwords | Support 150 groups (unlimited dynamic password) |
| Card type | M1 card |
| Number of IC cards | 200 sheets |
| The way to open the door | App,Code,IC card,Mechanical key |
| Alternative | Tuya,TTLOCK、Lora、Nb-iot（choose one from four） |
