•Metal frame(high quality aluminium alloy)
•Patented clutch design
•Highly integrated internal structure design
•Customizable door magnets
•PC material one-time hot press molding:high temperature/low temperature resistance,resistance resistance
•Metal frame and handle painting process:primer+color paint+varnish glaze
•Door lock networking
•Semiconductor fingerprints
•Touchscreen input
•Door opening app for your phone
•Numeric code to open the door
•Can be redeveloped
•Suitable for families,villas,hotels,apartments,rental houses
Specification: | |
Outer lock size | 335*76*25 |
Panel material | High quality aluminum alloy |
Surface technology | Fuel injection + electrophoresis |
Fit the lock body | 6052,6068 |
Door thickness requirements | 40-110mm |
Lock head | Super Class B mechanical lock |
Operating temperature | -20°C-+60°C |
Networking mode | Bluetooth、Lora、Nb-iot(choose one from three) |
Power supply mode | 4 alkaline batteries |
Low voltage alarm | 4.8V |
Standby current | 60μm |
Operating current | <200mA |
Unlock time | ≈1.5s |
Key type | Capacitive touch key |
Fingerprint head type | Semiconductor(ZFM-10)<0.001%<1.0% |
FFR | <0.001% |
FAR | <1.0% |
Number of passwords | Support 150 groups (unlimited dynamic password) |
Card type | M1 card |
Number of IC cards | 200 sheets |
The way to open the door | App,Code,IC card,Mechanical key |
Alternative | Tuya,TTLOCK、Lora、Nb-iot(choose one from four) |
